Guide to Network Topology

[F_J]

The way devices connect seems simple.

But it can make or break a network.

Network topologies define how devices link together.

But they also shape how the entire system behaves.

Let’s explore five common types:

1. Bus Topology
   → All devices share a single backbone.
   → One break, and the whole chain suffers.

2. Star Topology
   → Everything connects to a central hub.
   → If the hub fails, the network collapses.

3. Ring Topology
   → Devices form a closed loop.
   → Data moves in one direction, like a traffic circle.

4. Mesh Topology
   → Each device connects to every other.
   → It’s complex but highly reliable.

5. Hybrid Topology
   → Combines elements of star and bus.
   → Ideal for handling complex, growing networks.

A well-chosen topology isn’t just efficient—it’s future-proof.

Thanks for reading.
