This single visualization beautifully captures the soul of 5G Physical Layer — from modulation to coding to throughput performance
Breakdown of What’s Happening:
- QAM Signal Generation – Each symbol carries multiple bits.
- Constellation Diagram – Represents how symbols are mapped in I/Q space (here, 4-QAM = 4 symbols).
- BER Performance – As SNR increases, bit errors drop sharply
- LDPC Encoding – Used for Data Channels (high reliability, high throughput).
- Polar Coding – Used for Control Channels (optimized for short block lengths).
- Throughput vs SNR – Higher SNR = Better modulation efficiency.
- Coding Gain & 5G MCS Table – Shows trade-offs between rate and reliability.
Key Insight:
5G’s power lies in adaptive modulation and coding (AMC) — dynamically choosing the best modulation and code rate depending on channel conditions.
That’s how your phone maintains both speed
and stability
even when you move or signal fluctuates!
