Indoor Unit (IDU)
-
Function: Processes baseband signals and converts them to Intermediate Frequency (IF).
-
Purpose: Acts as the central control unit for modulation/demodulation and network interfacing
-
-
Outdoor Unit (ODU)
-
Function: Converts IF signals from the IDU to Radio Frequency (RF) for transmission.
-
Purpose: Mounted near the antenna to reduce signal loss and amplify RF signals
-
-
Antenna
-
Function: Radiates and receives microwave signals.
-
Types:
- Parabolic Dish Antenna (high gain for long distances).
- Flat Panel Antenna (compact for short links).
- Grid Antenna (lighter, used in medium-range links)
-
-
IF Cable (Intermediate Frequency Cable)
-
Function: Connects the IDU to the ODU, carrying IF signals and DC power.
-
Purpose: Ensures seamless communication between indoor and outdoor units
-
-
Coupler
-
Function: Splits or combines microwave signals with minimal loss.
-
Purpose: Allows signal redundancy or distribution for multiple ODUs
-
-
Orthomode Transducer (OMT)
-
Function: Combines and separates signals of two polarizations (vertical and horizontal).
-
Purpose: Increases link capacity without increasing spectrum usage
-
-
Waveguide
-
Function: Carries RF signals between the ODU and antenna with low signal loss.
-
Purpose: Used in high-frequency setups to maintain signal integrity
-
-
Power Supply Unit (PSU)
-
Function: Provides DC power to the IDU and ODU.
-
Purpose: Ensures continuous operation of the system, often includes battery backup
-
-
Alignment Tools
-
Function: Ensures precise antenna alignment for optimal signal performance.
-
Types: GPS-based tools, optical alignment scopes, signal analyzers
-
-
E-Band Radio (70/80 GHz)
-
Function: Provides ultra-high-capacity short-range links.
-
Purpose: Ideal for urban backhaul and data center connections with multi-Gbps capacity
-
-
Universal Backhaul Radio (UBR)
-
Function: Multi-band radio for wireless backhaul applications.
-
Purpose: Provides connectivity across various frequency bands (6–42 GHz)
-
-
Network Management System (NMS)
-
Function: Software to monitor and manage the microwave link.
-
Purpose: Enables real-time performance tracking and fault detection
-
-
Mounting Hardware
-
Function: Secures antennas and ODUs to towers, rooftops, or poles.
-
Types: Brackets, clamps, and mounting kits for stability and alignment
-
-
Surge Protector
-
Function: Protects the microwave link equipment from lightning strikes and power surges.
-
Purpose: Ensures system safety and reliability
-
-
Safety Rod
-
Installed at the highest point of the antenna structure (towers, poles, rooftops).
-
Used in microwave communication systems, especially in areas prone to thunderstorms.
