AT (ATtention) commands for UE Testing

TechRadar · February 22, 2023, 11:30pm

AT (ATtention) commands can be used to test a UE (User Equipment) in a telecommunication network.

Here are some commonly used AT commands for testing UE:

AT: This command is used to check if the UE is responding.
AT+CGSN: This command is used to get the serial number of the UE.
AT+CGMI: This command is used to get the manufacturer name of the UE.
AT+CGMM: This command is used to get the model name of the UE.
AT+CPIN: This command is used to enter the SIM card PIN code.
AT+CSQ: This command is used to check the signal strength of the network.
AT+CREG?: This command is used to check the network registration status of the UE.
AT+CGACT?: This command is used to check the PDP (Packet Data Protocol) activation status of the UE.
AT+CGATT?: This command is used to check the attachment status of the UE to the GPRS (General Packet Radio Service) network.
AT+COPS?: This command is used to get the network operator’s name and information.
ATD: This command is used to dial a phone number.
ATA: This command is used to answer an incoming call.
ATH: This command is used to hang up a call.

Here are some useful links to AT command references and resources:

3GPP AT Commands: This is the official AT command reference from the 3rd Generation Partnership Project (3GPP), the organization that develops the technical specifications for cellular networks. It covers AT commands for GSM, GPRS, UMTS, and LTE networks.
Link: https://portal.3gpp.org/desktopmodules/Specifications/SpecificationDetails.aspx?specificationId=1515
AT Commands Manual for GSM/GPRS Modems: This is a comprehensive manual that covers AT commands for GSM/GPRS modems, including commands for SMS, voice, and data communication.
Link: https://www.sparkfun.com/datasheets/Cellular%20Modules/AT_Commands_Manual_V1.11.pdf
Sierra Wireless AT Command Reference: This is the AT command reference for Sierra Wireless modems, including commands for GSM, CDMA, and LTE networks.
Link: https://source.sierrawireless.com/resources/airprime/software/airprime_-_swi_at_command_reference_r9/
Quectel AT Commands Manual: This is the AT command reference for Quectel modems, including commands for GSM, UMTS, LTE, and NB-IoT networks.
Link: https://www.quectel.com/download-zone
Huawei AT Command Reference: This is the AT command reference for Huawei modems, including commands for GSM, UMTS, LTE, and 5G networks.
Link: https://uniportal.huawei.com/uniportal1/?redirect=https%253A%252F%252Fsupport.huawei.com%252Fenterprise%252Fen%252Fdoc%252FEDOC1100158823%252F16f36bda%252Fat-command-reference

Note that the exact set of commands supported by a UE depends on its manufacturer and model, as well as the network it is connected to.
