5G Anchor Cell Mapping for 4G User Monitoring

5G NR
, , ,
1

Hello experts,

Can anyone help me with Nokia 5G cell anchor mapping?

I need a list that I can use to monitor 4G users. What is the MO (Managed Object) to find the 5G anchor cell mapping?

Any ideas?

5G Anchor Cell Mapping for 4G User Monitoring
5G Anchor Cell Mapping for 4G User Monitoring1024×1024 110 KB

1 Like
2

To designate a 4G site as an anchor, several conditions must be met. Below is a simplified checklist for verification:

  • Feature Activation: The LTE4088 EN-DC feature must be enabled with LNBTS-actLteNrDualConnectivity=true.
  • Neighbor Relation: The 4G site must have at least one operational LNADJGNB, ensuring:
    • LNADJGNB-administrativeState=unlocked
    • LNADJGNB-x2ToGnbLinkStatus=available
  • Cell Configuration: At least one LNRELGNBCELL must be operational and support dual connectivity (DC). Verify:
    • LNRELGNBCELL-lteNrDualConnectAllowed=allowed
    • LNRELGNBCELL-nrStatus=available

Meeting these conditions ensures that the 4G site is properly configured as an anchor for EN-DC operations.

There are numerous other configurations to verify, but the checks mentioned above should be the first priority.

1 Like
